Circuitul funcționează alimentat între 2,7V și 5,5V și furnizează semnal de ieșire dreptunghiular ''rail-to-rail'', cu un ciclu de serviciu de 50%. Valoarea frecvenței este setată cu un singur rezistor extern de 10—25kΩ, cuplat între masă și pin-ul RSET. Un divizor intern permite divizarea frecvenței interne de tact la 1, 2 sau 4. Astfe, pentru fiecare valoare a lui RSET există trei frecvențe posibile.
Circuitul funcționează alimentat între 2,7V și 5,5V și furnizează semnal de ieșire dreptunghiular ''rail-to-rail'', cu un ciclu de serviciu de 50%. Valoarea frecvenței este setată cu un singur rezistor extern de 10—25kΩ, cuplat între masă și pin-ul RSET. Un divizor intern permite divizarea frecvenței interne de tact la 1, 2 sau 4. Astfe, pentru fiecare valoare a lui RSET există trei frecvențe posibile.


[[Fișier:Diagrama bloc - LTC6905.svg|640px|none|Diagrama bloc - LTC6905]]
[[Fișier:Diagrama bloc - LTC6905, PNG.png|640px|none|Diagrama bloc - LTC6905, PNG]]


As shown in the Block Diagram, the LTC6905’s master oscillator is controlled by the ratio of the voltage between the V+ and SET pins and the current entering the SET pin (IRES). The voltage on the SET pin is forced to approxi- mately 1V below V+ by the PMOS transistor and its gate bias voltage.
As shown in the Block Diagram, the LTC6905’s master oscillator is controlled by the ratio of the voltage between the V+ and SET pins and the current entering the SET pin (IRES). The voltage on the SET pin is forced to approxi- mately 1V below V+ by the PMOS transistor and its gate bias voltage.

Versiunea de la data 24 ianuarie 2020 15:46

Work in progress. :)

Circuitul funcționează alimentat între 2,7V și 5,5V și furnizează semnal de ieșire dreptunghiular rail-to-rail, cu un ciclu de serviciu de 50%. Valoarea frecvenței este setată cu un singur rezistor extern de 10—25kΩ, cuplat între masă și pin-ul RSET. Un divizor intern permite divizarea frecvenței interne de tact la 1, 2 sau 4. Astfe, pentru fiecare valoare a lui RSET există trei frecvențe posibile.

Diagrama bloc - LTC6905, PNG
Diagrama bloc - LTC6905, PNG

As shown in the Block Diagram, the LTC6905’s master oscillator is controlled by the ratio of the voltage between the V+ and SET pins and the current entering the SET pin (IRES). The voltage on the SET pin is forced to approxi- mately 1V below V+ by the PMOS transistor and its gate bias voltage. A resistor RSET, connected between the V+ and SET pins, “locks together” the voltage (V+ – VSET) and current, IRES, variation. This provides the LTC6905’s high precision. The master oscillation frequency reduces to:

fOSC=(168.5MHz×10kΩRSET+1.5MHz)×1N
